Stainless Steel Flanges 316 |
| ||
How to Size Your Flange
If you are not sure how to match an existing flange, simply supply us with the details listed below and we can size it for you....
If you are not sure how to match an existing flange, simply supply us with the details listed below and we can size it for you....
- The outside diameter of the flange
- The hole centre distance across the radius (PCD)
- The thickness of the flange
- The number of bolt holes
- The bolt diameter
