Rubber Hose
Rubber Water Suction Hose
Recommended Usages: Slurry, Muddy Water, Drain Water
Cover: Blended SBR
Reinforcement: High Tensile Nylon Plies with Wire Steel Helix
Tube: Blended SBR
Temperature Range: -15° to 70º C
Recommended Usages: Slurry, Muddy Water, Drain Water
Cover: Blended SBR
Reinforcement: High Tensile Nylon Plies with Wire Steel Helix
Tube: Blended SBR
Temperature Range: -15° to 70º C
|
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Rubber Water Delivery Hose
Recommended Usages: Slurry, Muddy Water, Drain Water
Cover: Blended SBR
Reinforcement: High Tensile Nylon Plies
Tube: Blended SBR
Temperature Range: -15°to 70º C
Recommended Usages: Slurry, Muddy Water, Drain Water
Cover: Blended SBR
Reinforcement: High Tensile Nylon Plies
Tube: Blended SBR
Temperature Range: -15°to 70º C
|
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Rubber Oil Suction Hose
Recommended Usages: Suction & delivery of petroleum products
Cover: Oil resistant Nitrile
Reinforcement: High Tensile Nylon Plies with Wire Steel Helix
Tube: Nitrile
Temperature Range: -20° to 75º C
Recommended Usages: Suction & delivery of petroleum products
Cover: Oil resistant Nitrile
Reinforcement: High Tensile Nylon Plies with Wire Steel Helix
Tube: Nitrile
Temperature Range: -20° to 75º C
|
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Rubber Oil Delivery Hose
Recommended Usages: Transfer of oil & petroleum based products
Cover: Oil resistant Nitrile
Reinforcement: High Tensile Nylon Plies
Tube: Nitrile
Temperature Range: -25°to 75º C
Recommended Usages: Transfer of oil & petroleum based products
Cover: Oil resistant Nitrile
Reinforcement: High Tensile Nylon Plies
Tube: Nitrile
Temperature Range: -25°to 75º C
|
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Rubber Mako Marine Fuel Filler Hose
USCG/SAE J1527 Type A1 - Flame Retardant
Recommended Usages:
Type 1A fill hose is constructed with high grade chemigum tube for superiorfill applications. This is the connection from the boats fuel fill port down to the boats fuel tanks.
USCG/SAE J1527 Type A1 unleaded resistant.
Cover: Flame Retardant
Reinforcement: Two-ply synthetic braid with wire helix.
Tube: Black Nitrile
Temperature Range: -30ºC to 90ºC
USCG/SAE J1527 Type A1 - Flame Retardant
Recommended Usages:
Type 1A fill hose is constructed with high grade chemigum tube for superiorfill applications. This is the connection from the boats fuel fill port down to the boats fuel tanks.
USCG/SAE J1527 Type A1 unleaded resistant.
Cover: Flame Retardant
Reinforcement: Two-ply synthetic braid with wire helix.
Tube: Black Nitrile
Temperature Range: -30ºC to 90ºC
|
| ||||||||||||||||||||||||||||||||
Mako Marine Fuel Line
USCG/SAE J1527 Type A1
Fuel feed & vent applications on marine pleasure crafts. This hose meets or exceeds US Coast Guard requirements for type A1 services as outlined SAE J1527
Cover: Flame RetardantSynthetic Rubber
Reinforcement: Synthetic Braid
Tube: Black Nitrile
Temperature Range: -30°to 90º C
USCG/SAE J1527 Type A1
Fuel feed & vent applications on marine pleasure crafts. This hose meets or exceeds US Coast Guard requirements for type A1 services as outlined SAE J1527
Cover: Flame RetardantSynthetic Rubber
Reinforcement: Synthetic Braid
Tube: Black Nitrile
Temperature Range: -30°to 90º C
|
| |||||||||||||||||||||||||||||||||||||
Mako Marine Exhaust Rubber Hose
SPECIALLY DESIGNED FOR THE MARINE INDUSTRY
For conveying wet exhaust fumes.
Lloyds approved.
Light weight corrugated construction gives excellent flexibility
Cover: Corrugated cover. Black with blue stripe. Synthetic (corrugated finish). Ozone and oil resistant and flame resistant.
Reinforcement: High tensile textile cords with embedded steel helix wires.
Tube: NBR handles 40% Aromatics
Temperature Range: -20ºC to 121ºC
Working Pressure:5 Bar, 3:1 Safety Factor
SPECIALLY DESIGNED FOR THE MARINE INDUSTRY
For conveying wet exhaust fumes.
Lloyds approved.
Light weight corrugated construction gives excellent flexibility
Cover: Corrugated cover. Black with blue stripe. Synthetic (corrugated finish). Ozone and oil resistant and flame resistant.
Reinforcement: High tensile textile cords with embedded steel helix wires.
Tube: NBR handles 40% Aromatics
Temperature Range: -20ºC to 121ºC
Working Pressure:5 Bar, 3:1 Safety Factor
| Download as PDF |
| Product Code |
I.D. mm |
Bend Radius |
Kg/ MT |
Coil/ MT |
T-bolt to Suit |
| H23-020 | 19 | 115 | 0.418 | 20,60 | 702-029 |
| H23-022 | 22 | 133 | 0.46 | 20,60 | 702-031 |
| H23-025 | 25 | 152 | 0.525 | 20,60 | 702-035 |
| H23-028 | 28 | 172 | 0.576 | 20,60 | 702-039 |
| H23-032 | 32 | 191 | 0.646 | 20,60 | 702-041 |
| H23-035 | 35 | 209 | 0.685 | 20,60 | 702-043 |
| H23-038 | 38 | 229 | 0.737 | 20,60 | 702-047 |
| H23-042 | 42 | 248 | 0.806 | 20,60 | 702-051 |
| H23-045 | 45 | 261 | 0.855 | 20,60 | 702-053 |
| H23-048 | 48 | 286 | 1.005 | 20,60 | 702-057 |
| H23-050 | 51 | 406 | 1.062 | 20,60 | 702-059 |
| H23-057 | 57 | 458 | 1.197 | 20,60 | 702-067 |
| H23-060 | 60 | 482 | 1.233 | 20,60 | 702-070 |
| H23-063 | 63 | 508 | 1.299 | 20,60 | 702-073 |
| H23-070 | 70 | 559 | 1.423 | 20,60 | 702-079 |
| H23-073 | 73 | 590 | 1.48 | 20,60 | 702-082 |
| H23-076 | 76 | 610 | 1.457 | 20,60 | 702-085 |
| H23-090 | 90 | 711 | 1.71 | 20,60 | 702-097 |
| H23-100 | 102 | 813 | 2.054 | 20,60 | 702-112 |
| H23-114 | 114 | 914 | 2.325 | 20 | 702-125 |
| H23-125 | 125 | 1016 | 2.575 | 20 | 702-139 |
| H23-150 | 152 | 1219 | 3.18 | 20 | 702-161 |
| H23-200 | 203 | 1626 | 5.496 | 12 | 702-213 |
| H23-250 | 250 | 2032 | 7.666 | 12 | 702-265 |
| H23-300 | 300 | 11.365 | 12 | 702-322 |
Red Multipurpose Rubber Hose
Recommended Usages:
This high quality multipurpose hose is suitable for conveying air, water, oil, all alcohol blended fuel and all petroleum based products.
Cover: Red non-conductive weather and oil resistant
Reinforcement: Braided synthetic cord
Tube: Black smooth 50% aromatic Nitrile tube
Temperature Range: -25ºC to 95ºC
4:1 Safety Factor
Recommended Usages:
This high quality multipurpose hose is suitable for conveying air, water, oil, all alcohol blended fuel and all petroleum based products.
Cover: Red non-conductive weather and oil resistant
Reinforcement: Braided synthetic cord
Tube: Black smooth 50% aromatic Nitrile tube
Temperature Range: -25ºC to 95ºC
4:1 Safety Factor
| Download as PDF |
| Product Code |
I.D. mm |
O.D. mm |
W.P PSI |
Coil/ MT |
| MPRED-005 | 4.8 | 12 | 290 | 200 |
| MPRED-006 | 6.4 | 13 | 290 | 200 |
| MPRED-008 | 7.9 | 15 | 290 | 200 |
| MPRED-010 | 9.5 | 17 | 290 | 200 |
| MPRED-012 | 12.7 | 21 | 290 | 152 |
| MPRED-016 | 15.8 | 26 | 290 | 152 |
| MPRED-020 | 19.1 | 29 | 290 | 152 |
| MPRED-025 | 25.4 | 36 | 290 | 152 |
| MPRED-032 | 31.4 | 44 | 290 | 60 |
| MPRED-038 | 38.1 | 54 | 290 | 60 |
| MPRED-050 | 50.8 | 67 | 290 | 60 |
Hi-Flex Mobile Hydraulic Swaging Service
In-house Hydraulic & Industrial Crimping.
We carry Alfa Hydraulic Hose & a range of
Crimp fittings to suit.
Also available JIC, BSPT,BSPP & UNO, Metric Light & Heavy fittings Crimp range 1/4” - 6”
Field attachable fittings BSP, JIC
In-house Hydraulic & Industrial Crimping.
We carry Alfa Hydraulic Hose & a range of
Crimp fittings to suit.
Also available JIC, BSPT,BSPP & UNO, Metric Light & Heavy fittings Crimp range 1/4” - 6”
Field attachable fittings BSP, JIC
